GM '05-'18 LS High Performance Ignition Coils with Stock Style Brackets - Black
GM '05-'18 LS High Performance Ignition Coils with Stock Style Brackets - Black
SKU: SKU: 81022BKKT
Out of stock
Product Details
Features
- Coils put out a crazy 40,000 volts
- Brackets available in black and natural finishes
Description
TSP's LSX ignition coils feature magnetic steel cores specially designed to deliver up to 15% more spark than OEM. They use a premium epoxy material for added resistance to shock and vibration at high RPM. Replace your boring stock brackets with a billet aluminum pair from TSP, available in black and natural finishes. This coil and bracket are in the style of the Delco D510C.
Specs
| Bracket Material | Billet Aluminum |
| Coil Style | Coil Pack |
| Internal Construction | Epoxy |
| Primary Resistance | 0.500 Ohms |
| Secondary Resistance | 2,000 Ohms |
| Maximum Voltage | 40,000 Volts (V) |
| Spark Duration | 300 Microseconds (µs) |
| Peak Current | 220 Milliamperes (Ma) |
| Turns Ratio | 75:1 |
| Inductance | 2.7 Millihenrys (Mh) |
| Coil Wire Attachment | Female |
Fitment
COMPATIBLE WITH
CHEVROLET SMALL BLOCK V8 GEN. III/IV (LS BASED)
• 4.8 L / 293 in3
• 5.3 L / 325 in3
• 6.0 L / 364 in3
• 6.2 L / 376 in3
• 7.0 L / 427 in3
NOTE: Fits most LS2, LS3, and LS7 car applications.
Emissions Notice
This product does not affect vehicle emissions and is not subject to emissions compliance regulations.
