Chrysler Big Block A/C, Power Steering & Alternator System (383-440) - Polished
Chrysler Big Block A/C, Power Steering & Alternator System (383-440) - Polished
SKU: SKU: 383-AC-SYSTEM
Low stock
Product Details
Features
- Complete V-belt system for the big block Chrysler 383, 400, 426, and 440 tall deck Hemi engines with alternator, power steering and A/C.
- Saginaw power steering pump, Sanden 508 style compressor and 100A alternator NOT included.
Description
Chrysler Big Block 383-440 Alternator, PS Pulley and A/C Bracket System
Complete V-belt system for the big block Chrysler 383, 400, 426, and 440 tall deck Hemi engines with alternator, power steering and A/C.
Kit Includes:
• BCRL2KIT-A (2 Groove Crank Pulley, 1 Groove Water Pump Pulley and 1 Groove Alternator Pulley)
• 440-ALTBRKT
• 440-PSBRKT
• 440-ACBRKT
• BCR3PS keyway power steering pulley
Saginaw power steering pump, Sanden 508 style compressor and 100A alternator NOT included.
Requires:
Saginaw Power Steering Pump with 5/8" Keyway with mounting stud in lower right corner on the back of the pump.
Specs
| Product Type | V-Belt System |
| Power Steering | Yes - Saginaw |
| Finish | Polished |
| Belt Type | V-Belt |
| Water Pump Type | Mechanical |
| Make | Chrysler |
Fitment
Compatible with:
Big Block Chrysler 383, 400, 426, and 440 tall deck Hemi engines with alternator, power steering and A/C.
• 6.3 L / 383 in³
• 6.6 L / 400 in³
• 7.0 L / 426 Wedge
• 7.2 L / 440 in³
• 7.0 L / 426 Hemi
Requires: Saginaw Power Steering Pump with 5/8" Keyway with mounting stud in lower right corner on the back of the pump.
Emissions Notice
This product does not affect vehicle emissions and is not subject to emissions compliance regulations.
Chrysler Big Block A/C, Power Steering & Alternator System (383-440) - Polished
Chrysler Big Block 383-440 Alternator, PS Pulley and A/C Bracket System
Complete V-belt system for the big block Chrysler 383, 400, 426, and 440 tall deck Hemi engines with alternator, power steering and A/C.
Kit Includes:
- BCRL2KIT-A (2 Groove Crank Pulley, 1 Groove Water Pump Pulley and 1 Groove Alternator Pulley)
- 440-ALTBRKT
- 440-PSBRKT
- 440-ACBRKT
- BCR3PS keyway power steering pulley
Saginaw power steering pump, Sanden 508 style compressor and 100A alternator NOT included.
Requires:
- Saginaw Power Steering Pump with 5/8" Keyway with mounting stud in lower right corner on the back of the pump.
Compatible with:
Big Block Chrysler 383, 400, 426, and 440 tall deck Hemi engines with alternator, power steering and A/C.
• 6.3 L / 383 in³
• 6.6 L / 400 in³
• 7.0 L / 426 Wedge
• 7.2 L / 440 in³
• 7.0 L / 426 Hemi
| Product Type | V-Belt System |
| Power Steering | Yes - Saginaw |
| Finish | Polished |
| Belt Type | V-Belt |
| Water Pump Type | Mechanical |
| Make | Chrysler |
